The “new” AVR1000 has been develod with a carbon fiber ringslip ring contacts and a pre-stretch carriage up to 300% ratio.

The principle of the “ring”, allows to execute the wrapping cycle without any movement of the pallet load. As a consequence, the quality and the stability of the pallet load are not endangered and important production capacities remain guaranteed.

Possibility to start and stop the wrapping cycle at any height of the pallet load, allowing specific wrapping programs, such as top wrapping and single wrapping.

Strong points: exclusive and patented pre-stretch system, high speed, simplicity and flexibility. The results are a largely increased reliability and reduced maintenance as well as stable loads with minimal film consumption.

At the end of the cycle, the final film tail is safely inserted under the previous wrap or welded with halogen lamp device (based on option choosen). As results no loose film ends, guaranteeing a perfect finishing as well as no pallet alignment needed as the system detects and moves towards the pallet.


Options available:

– Motorized pantograph top press, stabilizer;
– Gravity stabilizer press;
– Lifting device;
– Single band lower;
– Double twin band lower;


  • Hourly output: up to 100 packs hour (120 packs/h with twin carriages version)
  • Rotation speed adjustable: Up to 54 rpm
  • Roll width: 500 mm
  • Roll weight: Max 20 kg
  • Film thickness: From 15 to 35 micron
  • Electrical power supply: 3 Ph 400V 50Hz
  • Installed power: 9 kW
  • Working air pressure: 5,5 ÷ 6,5 bar
